Tipping Trailers

Graham Edwards Flat Bed Tipping Trailers are built on a rigid framework and are fully galvanized for a long service life. Also the tipping operation is operated by an electric pump and the tailgate is double hinged to allow for easy tipping.

The battery has a trickle charge cable and the ten and twelve foot trailers have a built in ramp store. Like all our trailers, these Tipping Trailers are built to last.

Our Tippers are also provided with essential features such as electric tipping pump, double hinged tailgate, auto-reverse brakes and heavy duty jockey wheel. Optional extras and add-ons are also available.

Models

TP85
Gross Weight
2000KG
Unladen Weight
720KG
Length
8'
Width
5'
Bed Height (Inches)
25
Number of Axles
TANDEM
Tyre Size
155 X 12
TP105
Gross Weight
2700KG
Unladen Weight
840KG
Length
10'
Width
6'
Bed Height (Inches)
26
Number of Axles
TANDEM
Tyre Size
195 X 13
TP106
Gross Weight
3500KG
Unladen Weight
970KG
Length
10'
Width
6'6"
Bed Height (Inches)
28
Number of Axles
TANDEM
Tyre Size
185 X 13
TP126
Gross Weight
3500KG
Unladen Weight
1060KG
Length
12'
Width
6'6"
Bed Height (Inches)
28
Number of Axles
TANDEM
Tyre Size
185 X 13

Our standard tipping trailer has a very high specification with numerous details such as a trickle charge cable that ensure that the standard tipper trailer is always ready to go to work. See table below for other standard features.

Our tipper trailers all have the following features:

  • Rigid Framework
  • Fully Galvanized
  • Drop Down Sides
  • Electric Pump
  • Double Hinged Tail-gate
  • 18mm Phenol Coated Plywood Floor
  • Rubber Suspension
  • Tandem Axles
  • Spare Wheel Bracket
  • Auto-Reversing Brakes
  • Lockable Coupling
  • Removable Headboard
  • Battery C/W Trickle Charge
  • H.D Jockey Wheel
  • Protective Light Boxes
  • Ramp Store (Not TP85)



Check out this video of our GP with Livestock kit upgrade.



Although fitted with many features as standard we offer many optional extras which enable you to customise your trailer so that it fits your own specific trailer needs. Please note pictures shown vary in optional extras.
